CSS has a value for the display attribute called run-in. It’s like this:

h3 { display: run-in; }

The point is to allow a header to run into text below it, without sacrificing semantics or running into the problems you might run into trying to force it with other layout techniques.

Let’s take a closer look.

But why not __________?

But why not float it to the left? Well headers are often of larger font-size than body type. So if you float the header to the left, you might catch more than one line.

But why not make it an inline element? Because the following text might be (actually, is likely to be) inside of a paragraph tag. Paragraph tags are block-level, and thus the will break to a new line if they follow an inline element and the effect will not be achieved. You could insert the <h3> tag within the <p> tag, but that has semantic concerns, and more importantly, long term maintenance concerns. What if this effect goes out of vogue?

But why not use inline-block? Same problem as above. The effect will not be achieved unless you tuck the header into the following paragraph which is problematic.

How does it work then?

If a run-in element precedes a block level element, the run in element will behave structurally as if it has become the block level elements first inline child element.

Browser Support

Haven’t heard much about this? Well it might be because browser support is a bit weird.

Rumor has it that Mozilla isn’t happy with the spec. Firefox doesn’t support it at all, including the version 4 betas.

The WebKit family (Safari and Chrome) are supporting it, as well as Opera and IE 8. There are some differences in how these browsers handle things though. Reports have it that older versions of WebKit and Konqueror allowed run-in elements to run into succeeding inline elements which is incorrect.

Issues in the spec?

In my own reading of the spec, I find it a bit unclear.

If a sibling block box (that does not float and is not absolutely positioned) follows the run-in box, the run-in box becomes the first inline box of the block box.

That makes sense and appears to be how it works, but does “becomes the first inline box” mean that the run-in box should become a descendant of the block box? In WebKit, the run-in element retains its solidarity.

A run-in cannot run in to a block that already starts with a run-in or that itself is a run-in.

Does that mean that there can’t be two headers, both run-ins, that run into a paragraph below? That’s how I would read it, but I think the WebKit implementation where they both fall inside makes more sense. Opera and IE 8 follow the spec in that the first run-in becomes block and the second goes inline.

Then it says:

Otherwise, the run-in box becomes a block box.

Otherwise is a big word, but implementations have been pretty good here. Three run-in’s in a row inside a parent with no other siblings? They all go block. A run-in sandwiched between two inline elements? It goes block. Run-in > absolute-position > block, the run-in goes block. Mind-bending, I know, but current modern browsers are doing good here.

If the run-in element contains anything block-level, it becomes block-level. All browsers seem to agree on that one.

Demos

Here is my own simple demo page. There is also a super hardcore demo (which is over 10 years old).

Okay, okay; this may be a thank you posting for the wonderful sponsors of our massive HTML5 competition, however, it’s important for me to note that I refused to accept sponsors of any product that I didn’t honestly feel was fantastic. What this means is that, as the editor of Nettuts+, I fully endorse each and every one of the following services and products, and, in fact, use many of them on a daily basis! That’s why I asked these companies to sponsor the competition!

1. TechSmith

TechSmith has been extremely generous to Envato in the last few years. Luckily, that has no effect on the fact that the products they provide — everything from Camtasia Studio to Jing Pro, are amazing.

Did you know that I personally use their products every single day? When you watch screencasts from Nettuts+, they were recorded with Camtasia Studio for Mac. When I send out quickie videos and images, I use Jing Pro to distribute them on Twitter. Not only that, but they’re constantly updating their products, and support both Windows and Mac.

“We’ve stayed on top of the screen capture and recording game since the launch of Snagit nearly 20-years-ago.”

2. Media Temple

In addition to being my personal web host of choice, Media Temple is hugely respected around the web as being one of the premier web hosts. Whether hosting jQuery, or Starbucks, or even Django’s site, MediaTemple can handle the load! They come highly recommended.

“Media Temple hosts websites. Big and Small. For years we’ve taken complex technology and simplified it for the everyday website owner. Our products are designed to be powerful, affordable and relevant. Please take a look around; perhaps (mt) is a good choice for your next project.”

3. FormStack

Do we recommend FormStack? Well consider this; the submission form to enter the HTML5 competition…was created with FormStack. Their service is incredibly simple to use.

“Formstack’s easy form builder gives businesses and organizations an easy way to build any type of online form, integrate it with their website and begin collecting data. ”

4. Wufoo

At Envato, we use Wufoo as well. If you haven’t heard Chris, from CSS-Tricks praise Wufoo enough, let us assure you that their service comes with the highest recommendation from Nettuts+. I even use them on my own personal sites!

“What is Wufoo? Wufoo strives to be the easiest way to collect information over the Internet. Our HTML form builder helps you create contact forms, online surveys, and invitations so you can collect the data, registrations and online payments you need without writing a single line of code.

5. FusionCharts

FusionCharts has long been regarded as the premier solution for rendering animated graphs and charts for your business. Just browse through their various demos if you don’t believe me!

“FusionCharts v3 helps you create animated and interactive Flash charts for web and desktop applications. It livens up your applications by converting monotonous data into exciting visuals. “

6. Pagelime

We’ve published PageLime tutorials a couple of times on Nettuts+ recently. The huge advantage with their service is that zero coding is required on your part. This makes it significantly appealing to non-tech savvy folks. Most recently, they’ve launched a reseller program, as well as a new navigation manager.

“Pagelime is a brandable CMS that lets your clients manage their content. No installation, no coding to integrate, and no wasted time. Just add the cms-editable CSS class to any HTML element on your site and Pagelime does the rest.”

7. Campaign Monitor

There’s a reason why Facebook, Ebay, and Twitter utilize Campaign Monitor’s services: they’re the best! In fact, their email CSS guide has been proven to be a bible for me, when creating designs optimized for email. They even contributed a tutorial to Nettuts+ not too long ago on the state of CSS3 in email designs.

Send beautiful email campaigns, track the results, and manage your subscribers.”

8. Snippets

If you’ve watched my tutorials, you might have noticed a little scissors icon in my menu bar. That’s for Snippets. It’s an incredible code snippet management tool for Mac, that I use on a daily basis. Even better, it has support for Snipplr uploading — which Envato recently purchased!

“Snippets is a powerful application for Mac OS X that stores the most valuable pieces of code you can reuse in different projects many times.”

9. Querious

In need of a kick-ass MySQL database management app for Mac? I was, and Querious proved to be the best tool for the job. I use it often in my SQL-based video tutorials.

“Querious is a MySQL database management application written from the ground up for Mac OS X. Unlike mindless Mac OS X ports of applications originally made for Windows or Linux, Querious works the way you’d naturally expect it to as a Mac OS X app.”

10. Miva Merchant

Miva Merchant has been around for a long time, and is one of the top providers of e-commerce solutions on the web.

Miva Merchant is a leading supplier of e-commerce software and services to small and medium-sized businesses. We provide online merchants, developers, web designers and web hosts with the information and technology needed to be successful in today’s online selling environment.

11. Rockable Press

Envato’s publishing branch, Rockable Press, is in full force these days — especially with the release of our CEO’s newest book, “How to Build a Successful Blog Business,” which I’m currently reading through. To be objective…it’s fantastic.

“At Rockable Press, we produce simple, straight forward how-to guides and resources for web and creative professionals. We are a small web publishing outfit operated by Envato with authors based around the world. ”

12. jQuery Enlightenment

To this day, jQuery Enlightement holds the spot as my most recommended book on jQuery. Written by Cody Lindley, the book is succinct, and cuts out all of the fluff. As a result, you learn everything you need to know…as quickly as possible. Not only that, but he utilizes JSBin to provide clickable code examples for all of the demos. This has proven to be an extremely smart decision on his part, and you’ll surely see others adopting this same method in the future.

“jQuery Enlightenment was written to express, in short-order, the concepts essential to intermediate and advanced jQuery development. Its purpose is to instill in you, the reader, practices that jQuery developers take as common knowledge. Each chapter contains concepts essential to becoming a seasoned jQuery developer.”

13. WP Structure Theme

Chris Robinson is far and away one of the best authors on ThemeForest, and this theme is a perfect example of his talents.

“Months in development WP Structure is a highly flexible and heavily optioned premium theme, to be used for almost anything business, portfolio, blog, magazine & more!”

This exclusive premium video series will take you from a state of absolute CSS “noobness,” all the way up to ninja-status, capable of taking advantage of the latest CSS3 techniques. The series begins with the basics: the syntax, properties, etc. However, each new video expands upon the previous, as you work your way up and improve your skills. In this final week, you’ll complete the series, as you gain access to Parts 8-12: five new episodes.

In these final video tutorials, you’ll learn about a variety of CSS3 techniques, how to use custom fonts, working with CSS frameworks, and how to extend CSS with applications like LESS. Don’t fall behind! Become a Premium member!

The Full Screencast Series: Exclusive to Premium Members

• Part 1: Preparation
• Part 2: CSS Properties
• Part 3: Typography
• Part 4: Floats
• Part 5: Positioning
• Part 6: Semantics, List Items, and Menus
• Part 7: CSS Organizational Techniques
• Part 8: Rounded Corners, Box Shadows, and Text Shadows
• Part 9: CSS3 Gradients
• Part 10: Custom Fonts with @font-face
• Part 11: Taking Advantage of CSS Frameworks
• Part 12: Extending CSS with LESS

Join Net Premium

For those unfamiliar, the family of TUTS sites runs a premium membership service. For $9 per month, you gain access to exclusive premium tutorials, screencasts, and freebies from Nettuts+, Psdtuts+, Aetuts+, Audiotuts+, and Vectortuts+! For the price of a pizza, you’ll learn from some of the best minds in the business. Become a Premium member!

One of the cool new features of HTML5 is WebSockets, which let us talk to the server without using AJAX requests. In this tutorial, we’ll review the process of running a WebSocket server in PHP, and then building a client to send and receive messages to it over the WebSocket protocol.

What are WebSockets?

WebSockets is a technique for two-way communication over one (TCP) socket, a type of PUSH technology. At the moment, it’s still being standardized by the W3C; however, the latest versions of Chrome and Safari have support for WebSockets.

What do WebSockets Replace?

Websockets can replace long-polling. This is an interesting concept; the client sends a request to the server – now, rather than the server responding with data it may not have, it essentially keeps the connection open until the fresh, up-to-date data is ready to be sent – the client next receives this, and sends another request. This has its benefits: decreased latency being one of them, as a connection which has already been opened does not require a new connection to be established. However, long-polling isn’t really a piece of fancy technology: it’s also possible for a request to time-out, and thus a new connection will be needed anyway.

Many Ajax applications makes use of the above – this can often be attributed to poor resource utilization.

Wouldn’t it be great if the server could wake up one morning and send its data to clients who are willing to listen without some sort of pre established connection? Welcome to the world of PUSH technology!

Step 1: Get the WebSocket Server

This tutorial will focus more on the client building rather than server implementation.

I’m using XAMPP on Windows 7 to run the PHP server locally. Grab a copy of phpwebsockets which is a WebSocket server in PHP. (Note: I experienced some problems with this version, I made some changes to it and will including it in the source files) There are various WebSocket implementations; if one doesn’t work, you can try another or just continue with the tutorial.

• jWebSocket (Java)
• web-socket-ruby (ruby)
• Socket IO-node (node.js)

Start the Apache server Step 2: Change URLs and Ports

Change the server according to your setup, for example in setup.class.php:

public function __construct($host='localhost',$port=8000,$max=100) { $this->createSocket($host,$port); }

Browse through the files and make changes where appropriate.

Step 3: Start Building the Client

Lets get a basic template up; this is my client.php file:

<!DOCTYPE html> <html> <head> <script src="http://ajax.googleapis.com/ajax/libs/jquery/1.4.2/jquery.min.js"></script> <title>WebSockets Client</title> </head> <body> <div id="wrapper"> <div id="container"> <h1>WebSockets Client</h1> <div id="chatLog"> </div><!-- #chatLog --> <p id="examples">e.g. try 'hi', 'name', 'age', 'today'</p> <input id="text" type="text" /> <button id="disconnect">Disconnect</button> </div><!-- #container --> </div> </body> </html>​

So in this code we’re creating a simple template: we have a box for the chat log, an input box, and one disconnect button.

Step 4: Add Some CSS

Nothing fancy, just space some elements out.

body { font-family:Arial, Helvetica, sans-serif; } #container{ border:5px solid grey; width:800px; margin:0 auto; padding:10px; } #chatLog{ padding:5px; border:1px solid black; } #chatLog p { margin:0; } .event { color:#999; } .warning{ font-weight:bold; color:#CCC; } Step 5: WebSocket Events

First, let’s try and understand the idea of WebSocket events.

The Events

We’ll be using three events:

• onopen: When a socket has opened
• onmessage: When a message has been received
• onclose: When a socket has been closed

But how can we implement this?

First create a WebSocket object

var socket = new WebSocket("ws://localhost:8000/socket/server/startDaemon.php");

And checking for events is as simple as:

socket.onopen = function(){ alert("Socket has been opened!"); }

But what about when we receive a message?

socket.onmessage = function(msg){ alert(msg); //Awesome! }

However, let’s avoid using alert boxes, and actually integrate what we’ve learned into the client page.

Step 6: JavaScript

Ok, so let’s get started. First we put our code in jQuery’s document ready function, then we check whether the user has a WebSockets-enabled browser. If they do not, we append a link to Chrome in the HTML.

$(document).ready(function() { if(!("WebSocket" in window)){ $('#chatLog, input, button, #examples').fadeOut("fast"); $('<p>Oh no, you need a browser that supports WebSockets. How about <a href="http://www.google.com/chrome">Google Chrome</a>?</p>').appendTo('#container'); }else{ //The user has WebSockets connect(); function connect(){ //the connect function code is below } });

As you can see, if the user has WebSockets then we call a connect() function. This is the core of the functionality: we’ll start with the open, close and receive events.

We’ll define the URL of our server

var socket; var host = "ws://localhost:8000/socket/server/startDaemon.php";

Wait, where’s the http in that URL? Oh right, it’s a WebSocket URL, so it’s using a different protocol. Here’s a breakdown of the pieces of our URL:

Let’s continue with our connect() function. We will put our code within a try/catch block; so if something goes wrong, we can let the user know. We create a new WebSocket, and pass the message to a message function which I’ll explain later. We create our onopen, onmessage and onclose functions. Note that we also show the user the socket status; this is not necessary, but I’m including it here as it can be helpful for debugging.

• CONNECTING = 0
• OPEN = 1
• CLOSED = 2

function connect(){ try{ var socket; var host = "ws://localhost:8000/socket/server/startDaemon.php"; var socket = new WebSocket(host); message('<p class="event">Socket Status: '+socket.readyState); socket.onopen = function(){ message('<p class="event">Socket Status: '+socket.readyState+' (open)'); } socket.onmessage = function(msg){ message('<p class="message">Received: '+msg.data); } socket.onclose = function(){ message('<p class="event">Socket Status: '+socket.readyState+' (Closed)'); } } catch(exception){ message('<p>Error'+exception); } }

The message() function is fairly simple, it takes in some text that we want to show the user and appends it to the chatLog. We create the appropriate class for paragraph tags in the socket event functions which is why there is only one closing paragraph tag in the message function.

function message(msg){ $('#chatLog').append(msg+'</p>'); } So Far…

If you’ve been following up to this point, well done! We’ve managed to create a basic HTML/CSS template, create and establish a WebSocket connection and keep the user updated as progress was made with the connection.

Step 7: Sending Data

Now rather than having a submit button, we can detect when the user presses return on their keyboard, and run the send function. The ’13′ you see below is the ASCII key for the enter button.

$('#text').keypress(function(event) { if (event.keyCode == '13') { send(); } });

And here’s the send() function:

function send(){ var text = $('#text').val(); if(text==""){ message('<p class="warning">Please enter a message'); return ; } try{ socket.send(text); message('<p class="event">Sent: '+text) } catch(exception){ message('<p class="warning"> Error:' + exception); } $('#text').val(""); }

Remember what you see above may be a chunky bit of code, but in reality, the code we really need is:

socket.send(); //Thanks JavaScript

The extra code is doing a number of things: detecting if the user didn’t enter anything but still hit return, clearing the input box, and calling the message functions.

Step 8: Closing the Socket

Closing the socket is fairly straightforward: attach a click handler to our disconnect button and we’re done!

$('#disconnect').click(function(){ socket.close(); }); The Completed JavaScript $(document).ready(function() { if(!("WebSocket" in window)){ $('#chatLog, input, button, #examples').fadeOut("fast"); $('<p>Oh no, you need a browser that supports WebSockets. How about <a href="http://www.google.com/chrome">Google Chrome</a>?</p>').appendTo('#container'); }else{ //The user has WebSockets connect(); function connect(){ var socket; var host = "ws://localhost:8000/socket/server/startDaemon.php"; try{ var socket = new WebSocket(host); message('<p class="event">Socket Status: '+socket.readyState); socket.onopen = function(){ message('<p class="event">Socket Status: '+socket.readyState+' (open)'); } socket.onmessage = function(msg){ message('<p class="message">Received: '+msg.data); } socket.onclose = function(){ message('<p class="event">Socket Status: '+socket.readyState+' (Closed)'); } } catch(exception){ message('<p>Error'+exception); } function send(){ var text = $('#text').val(); if(text==""){ message('<p class="warning">Please enter a message'); return ; } try{ socket.send(text); message('<p class="event">Sent: '+text) } catch(exception){ message('<p class="warning">'); } $('#text').val(""); } function message(msg){ $('#chatLog').append(msg+'</p>'); } $('#text').keypress(function(event) { if (event.keyCode == '13') { send(); } }); $('#disconnect').click(function(){ socket.close(); }); }//End connect }//End else }); Step 9: Run the WebSocket Server

We will need command line access. Luckily, XAMPP has a handy shell option. Click ‘Shell’ on the XAMPP control panel, and type in:

php -q path\to\server.php

You have now started a WebSocket server!

Finished

When the page loads, a WebSocket connection will attempt to be established (try editing the code so the user has connect/disconnect option). Then, the user can enter messages and receive messages from the server.

That’s it!

Thanks for reading; I hope you enjoyed this tutorial! Remember, as exciting as WebSockets may be, things may change. You can refer here to keep up to date on the W3C WebSocket API.
